Xinje XC Series User Manual

8 expansion devices
8-3-4．XC-E4DA
0V
24V
VO2
C3AO2C2
VO0 VO1
C0 AO0 C1 AO1
VO3
AO3
CH
NAME
SIGNAL
CH
NAME
SIGNAL
CH0
AO0
Current analogue output
CH1
AO1
Current analogue output
VO0
Voltage analogue output
VO1
Voltage analogue output
C0
COM of CH0
C1
COM of CH1
Items
Voltage Output
Current Output
Analogue Output
Range
DC0～5V, 0～10V
(external load resistor
2KΩ~1MΩ)
DC0～20mA, 4～20mA
(external load resistor less than 500Ω)
Digital Input Range
12 bits binary
Distinguish Ratio
1/4095(12Bit); the convert data is stored in PLC in form of Hex. (12Bit)
Integral Precision
0.8%
Convert Speed
3ms/CH
Power Supply
DC24V±10%，100mA
 4CH analogue output: voltage and current input selectable; Voltage input range is 0～5V,
0～10V selectable, current input range is 0～20mA, 4～20mA selectable;
 10 bits high precision analogue output;
 As the special module, 7pcs XC-E4DA can be connected to one XC series PLC main unit;
