Xinje XC Series User Manual

2 The Specifications and Parameters of CPU
2-1-2．Performance and Specifications
Items
Specifications
Program Executing Form
Loop scan form
Program Form
Instruction、Ladder
Dispose Speed
0.5 us
Power Off Retentive
Use Flash ROM
User's program space
※
1
32KB
I/O points
※
2
Total I/O
10
16
24
32
Input
5
X0~X4
8
X0~X7
12
X0~X13
16
X0~X17
Output
5
Y0~Y4
8
Y0~Y7
12
Y0~Y13
16
Y0~Y17
Internal Coils (X)
※
3
X0~X77 (64)
Internal Coils (Y)
※
4
Y0~Y77 (64)
Internal Coils (M)
448
M0~M199
【M200~M319】
※
5
For Special Use
※
6
M8000~M8079
For Special Use
※
6
M8120~M8139
For Special Use
※
6
M8170~M8172
For Special Use
※
6
M8238~M8242
For Special Use
※
6
M8350~M8370
Flow (S)
32
S0~S31
Timer (T)
Points
80
T0~T23：100ms not accumulate
T100~T115：100ms accumulate
T200~T223：10ms not accumulate
T300~T307：10ms accumulate
T400~T403：1ms not accumulate
T500~T503：1ms accumulate
Spec.
100ms timer: set time 0.1~3276.7sec.
10ms timer: set time 0.01~327.67sec.
1ms timer: set time 0.001~32.767sec.
Counter (C)
Points
48
C0~C23: 16 bits sequential counter
C300~C315: 32 bits sequential/inverse counter
C600~C603: single phase high speed counter
C620~C621
C630~C631
Spec.
16 bits counter: set value K0~32,767
32 bits counter: set value -2147483648~＋2147483647
