Xinje XC Series User Manual

1-1．Products Specifications
1-1-1．CPU Units
XC series PLC's CPU units has many subsidiary products line, the combination can be make
freely.
 I/O Points: 10、14、16、24、32、42、48、60 points
 Output Type: Transistor、Relay、R/T mixed type
 Input Type: PNP、NPN
 Power Supply Type: AC220V、DC24V
 Subsidiary
※
1
XC1、XC2、XC3、XC5、XCM
Series
Type
Description
XC1
Economic Type
Include 10I/O、16I/O、24I/O、32I/O
Suitable for common simple applications which has less I/O
requirement, Do not support free communication, expansion, BD
cards.
XC2
Basic Type
Include 14I/O、16I/O、24I/O、32I/O、48I/O、60I/O
Equipped XC series PLC's basic functions, the CPU unit can't work
with expansions, but can work with BD card. Equipped with high
speed operation ability.
XC3
Standard Type
Include 14I/O、24I/O、32I/O、42I/O、48I/O、60I/O
XC series standard models, equipped with full functions, fulfill the
user's diverse requirements
XC5
Strength Type
Include 24I/O、32I/O、48I/O、60I/O
Besides XC3 series functions, XC5 series PLC added following
functions:
24I/O, 32I/O models have 4CH pulse output;
48I/O, 60I/O support CAN-bus, users can realize CAN bus network
functions
XCM
Motion Control
Type
Include 24I/O、32I/O
Besides XC series basic functions, XCM models support powerful
pulse output functions and rich motion control instruction. The
models are designed especially for motion control.
XCC
High speed
motion control
type
Include 32 I/O.
Besides XC series basic function, XCC models support motion
control instruction, more pulse output channels and high speed
counters.
 Special Type XC3-19AR-E (Combine analogue I/O with digital I/O in one body）
Diverse Models
1
