When programming the PLC via XCPPro, users can feel it Humanism and easy to get familiar.
 Switch ladder and instruction list freely
 Offer soft device comment, ladder comment, instruction hint functions etc.
 Offer many types of program interface for special instructions, convenient to write the
instructions.
 Perfect monitor mode: ladder monitor, free monitor, soft devices monitor
 Many windows in one interface, convenient to manage.
※1：For the detailed XCP Pro software application, please refer to XC series PLC user manual【software】.
1-1-2．Expansions
To fulfill the field control requirements better, XC series PLC can work with expansions, each
CPU units can link seven expansions.
 Diverse Types
Digital I/O expansions, analogue I/O modules, temperature control modules and mixed
function modules etc.
 Compact Size
 DC24V power supply (32I/O modules are AC220V power supply).
 Analogue、temperature modules all include PID tune function.
Easy to Program
3
Expansion Modules
1
Digital I/O
Modules
Power Supply: DC24V
AC220V
Input points: 8-32
Output points: 8-32
Output Type: Relay
Transistor
Analogue I/O
Modules
Power Supply: DC24V
Type: DA、AD
AD/DA
DA channel Nr.：2、4
AD channel Nr.: 4、8
Temperature
Control Modules
Power Supply: DC24V
Temperature: PT100
Thermocouple
Temp. Channel Nr.: 6
PID Control: Included
Function Mixed
Modules
Power Supply: DC24V
AD: 3CH
Temperature: 4CH PT100
DA: 2CH
