8 expansion devices
CH2
AO2
Current analogue output
CH3
AO3
Current analogue output
VO2
Voltage analogue output
VO3
Voltage analogue output
C2
COM of CH2
C3
COM of CH3
-
24V
+24V power supply
0V
COM of power supply
8-3-5．XC-E2DA
Items
Voltage Output
Current Output
Analogue Output Range
DC0～5V、0～10V
DC0～20mA、4～20mA
External Load Resistor (2KΩ~1MΩ)
External Load Resistor less than 500Ω
Digital Input Range
12 bits binary
Distinguish Ratio
1/4096(12Bit); the convert data is stored in PLC in form of Hex. (12Bit)
Integral Precision
0.8%
Convert Speed
3ms/CH
Power Supply
DC24V±10%，100mA
0V
24V
VO0 VO1
C0 AO0 C1 AO1
Brief Introduction
1
Specification
2
Terminal Arrangement
3
 2CH analogue output: voltage and current input selectable; Voltage input range is 0～5V、
0～10V selectable, current input range is 0～20mA、4～20mA selectable;
 12 bits high precision analogue input;
 As the special module, 7pcs XC-E2DA can be connected to one XC series PLC main unit;
