Xinje XC Series User Manual

8 expansion devices
CH4
VI0
AI0+ current input
CH5
VI1
AI1+ current input
C0
AI0- current input
C1
AI1- current input
CH6
VI2
AI2+ current input
CH7
VI3
AI3+ current input
C2
AI2- current input
C3
AI3- current input
-
24V
+24V power supply
0V
COM of power supply
8-3-2．XC-E4AD2DA
Items
Analogue Input
Analogue Output
Voltage Input
Current Input
Voltage output
Current Output
Analogue Input Range
0~5V,0~10V
0~20mA,4~20mA
-
Max Input Range
DC±18V
0~40mA
-
Analogue Output Range
-
0~5V、0~10V,
(external load
resistor
2KΩ~1MΩ)
0~20mA,4~20mA
(external load resistor
500Ω)
Digital Input Range
-
12bits binary (0~4095)
Digital Output Range
14 bits binary (0~16383)
-
 4CH analogue input: voltage and current input selectable; Voltage input range is 0～5V, 0～
10V selectable, current input range is 0～20mA, 4～20mA selectable;
 2CH analogue output: voltage and current input selectable; Voltage input range is 0～5V,
0～10V selectable, current input range is 0～20mA, 4～20mA selectable;
 14 bits high precision analogue input;
 As the special module, 7pcs XC-E4AD2DA can be connected to one XC series PLC main
unit;
 XC-E4AD2DA module four A/D channels have PID function.
Brief Introduction
1
Specification
2
