Xinje XC Series User Manual

2 The Specifications and Parameters of CPU
For Special Use
※
6
D8630~D8729
Flash ROM Register (FD)
512
words
FD0~FD127
For Special Use
※
6
FD8000~FD8383
High Speed Dispose
Ability
High speed counter, pulse output, external interruption
Password Protection
6 bits ASCII
Self-diagnose Function
Power on self-check、monitor the timer、grammar check
Items
Specifications
Program Executing Form
Loop scan form
Program Form
Instruction、Ladder
Dispose Speed
0.5 us
Power Off Retentive
Use Flash ROM and Li battery
User's program space
※
1
128K
I/O points
※
2
Total I/O
14
24
32
42
48
60
Input
8
X0~X7
14
X0~X15
18
X0~X21
24
X0~X27
28
X0~X33
36
X0~X43
Output
6
Y0~Y5
10
Y0~Y11
14
Y0~Y15
18
Y0~Y21
20
Y0~Y23
24
Y0~Y27
Internal Coils (X)
※
3
X0~X1037 (544)
Internal Coils (Y)
※
4
Y0~Y1037 (544)
Internal Coils (M)
8768
points
M0~M2999
【M3000~M7999】
※
5
For Special Use
※
6
M8000~M8767
Flow (S)
1024
points
S0~S511
【S512~S1023】
Timer
points
640
points
T0~T99：100ms not accumulate
T100~T199：100ms accumulate
T200~T299：10ms not accumulate
Flow (S)
T300~T399：10ms accumulate
T400~T499：1ms not accumulate
T500~T599：1ms accumulate
T600~T639：1ms precise time
Spec.
100ms timer: set time 0.1~3276.7sec.
10ms timer: set time 0.01~327.67sec.
1ms timer: set time 0.001~32.767sec.
Counter (C)
points
640
points
C0~C299: 16 bits sequential counter
C300~C598: 32 bits sequential/inverse counter
