Xinje XC Series User Manual

8 expansion devices
8-3-8．XC-E3AD4PT2DA
Items
Analogue Current Input
(AD)
Temperature Input
(PT)
Analogue Voltage
Output (DA)
Analogue input
DC0～20mA, 4～20mA
PT100
-
Temperature
testing range
-
-100~350℃
-
Max input range
DC0～40mA
-
-
Analogue output
range
-
-
DC0~5V,
0~10V(external load
resistor 2KΩ~1MΩ)
Digital input
range
-
-
10 bits Binary (0~1023)
Digital Output
Range
14 bits Binary (0~16383)
-1000~3500
-
Distinguish Ratio
1/16383(14Bit): The
converted data is stored
in PLC in Hex. (14Bit)
0.1℃
1/1023(10Bit): The
converted data is stored
in PLC in Hex. (10Bit)
PID Output Value
0~K4095
-
Integral Precision
0.8%
±0.5℃
0.8%
Convert Speed
20ms/CH
3ms/CH
Power Supply
DC24V±10%，100mA
Brief Introduction
1
Specification
2
 3CH 14bits current input、4CH PT100 temperature input and 2CH 10bits voltage output
 3CH AD is current (0~20mA、4~20mA) selectable; 2Ch DA is voltage (0~5V、0~10V)
selectable, choose via the software;
 Pt resistor input, the scale is PT100
 3CH A/D and 4CH PT input are equipped with PID auto tune function;
 As the special module, 7pcs XC-E3AD4PT2DA can be connected to one XC series PLC main
unit;
