Operator’s Manual Page 13
Operating the
5 Series
5 Series5 Series
5 Series
Note about operation with AudioCore software.
The following operating information covers setup and control of a 5 Series via the front panel controls only. Please
consult the manual supplied with this software for information regarding full computer control.
Start-up procedure
Switching on the unit will display a brief message detailing the unit type and software version running
== AudioCore DP548 ==
== AudioCore DP548 ==== AudioCore DP548 ==
== AudioCore DP548 ==
==Software V 1.00 ==
==Software V 1.00 ====Software V 1.00 ==
==Software V 1.00 ==
and all LEDs will briefly illuminate. The unit will then begin its countdown to the wake-up procedure
2
, during which time
the audio will fade up to the level last set. Metering will begin to operate when the fade-up starts.
Preliminary Set-up as a Crossover (DP548 & DP544)
The procedure below should be followed when first installing a 5 Series
5 Series 5 Series
5 Series unit as a crossover.
Design your crossover! To do this, press MENU, and use the BACK or NEXT key to select ‘Crossover
Crossover Crossover
Crossover
sub
subsub
sub -
--
-menu
menumenu
menu’ and then press ENTER. Use the BACK or NEXT key to select ‘Design a crossove
Design a crossoveDesign a crossove
Design a crossover
rr
r
and then press ENTER. Finally, use the BACK or NEXT key to select the desired routing
3
and follow the set-up
wizard to finalise your design.
Note that when in a menu, ENTER is always used to confirm selections. The current selection is marked with an
asterisk ‘*’.
Use the EDIT keys on each output channel with the BACK and NEXT keys to select the high pass filters, low
pass filters, parametrics etc. Note that when designing a new crossover, the high and low pass filters will be set
to default values.
Use the EDIT keys on each input channel with the BACK and NEXT keys to select the gain, delay and
parametrics available on each input.
Preliminary Set-up as Insert Channel Processing (DP544)
Follow the steps above, but choose 4 x 1 way as the desired routing – this will feed input A to output 1, input B to output
2 etc. so offering four independent channels of processing.
Note that if no action is taken in menu mode, the unit will return to normal ‘default’ mode after about twenty
(20) seconds. Repeat the above directions to return to menu mode.
2
The wake-up time countdown may be adjusted in the SYSTEM menu – see page 24 for details.
3
For details about adjusting the routing if one of the standard configurations does not suit, see page 15.
