XTA 5 series - Specifications and Warranty

      
            
      
Operator’s Manual Page 63
Specifications
Inputs: 4 electronically balanced
Impedance: > 10k ohms.
CMRR : >65dB 50Hz - 10kHz.
Outputs: 4/8 electronically balanced
Source Imp: < 60ohms
Min. Load: 600ohm
Max. Level: +20dBm into 600 ohm
Frequency Resp.:+½dB 20Hz-20kHz
-3dB @ 32kHz
Dyn. Range:>116dB 20Hz-20k unwtd
Distortion:< .02%@1kHz,+18dBm
Maximum Delay: 650 mS
Min Step Size: 0.3 µS
Input Gain: +6dB to -40dB in 0.1dB steps
Output Gain: +15dB to -40dB in 0.1dB steps and mute
Parametric Equalisation
8 per Input / 9 Sections per Output
Filter Gain: +15dB to -30dB in 0.1dB steps.
Freq. Range: 19.7Hz - 32kHz, 1/36 octave steps.
Filter Q / BW: 0.4 to 128 / 2.5 to 0.008
(Sections switched to shelving response)
Low frequency: 19.2Hz - 1kHz
High frequency: 1kHz - 32kHz
Shelf gains: ±15dB in 0.1dB steps.
Dyanamic Equalisation
3 bands per Input
Filter Gain: 6dB to 18dB max ceiling/floor.
Freq. Range: 19.7Hz - 32kHz, 1/36 octave steps.
Filter Q / BW: 0.4 to 128 / 2.5 to 0.008
Attack time: 0.07mS to 2.0S
Release time: 11mS to 3.4S
Threshold: -32dB to +22dB in 0.5dB steps
Max ratio: 4:1 (cut above) 2:1(all other modes)
High and Lowpass Filters
Filters: 1 of each per output.
Freq. Range HPF: 10Hz - 16kHz 1/36 octave steps.
Freq. Range LPF: 35Hz - 22kHz 1/36 octave steps.
Responses: 1
st
Order 6dB/Oct.
Bessel/Butterworth/Linkwitz-Riley 12-24-48dB/Oct.
Bessel/Butterworth 18dB/Oct.
Compressors
Threshold: +22dBu to -10dBu
Attack time: 0.07 to 512mS
Release time: 45mS to 3.4S
Knee control 0(hard) to 12(soft) in 13 steps
Max ratio: 16:1
Limiters
Program Limiter:
Threshold: +22dBu to -10dBu
Attack time: 0.3 to 90 milliseconds
Release time: 2/4/8/16/32 x Attack time
“D-Max” Limiter:
Attack Time: -60uS
Release Time: Slow/Medium/Fast
Matrix Mixer
Input sent to output: -40db - +15dB and mute
Display: 2 x 24 Character LCD
Input meter: 2 x 6 point, -24dB to digital clip.
Output meter: 8 x 6 point, -24dB to +4dB into limit.
Connectors
Inputs: 3 pin female XLR
Outputs: 3 pin male XLR.
External: 9 pin DEE connector (RS232)
RS485:3 pin male XLR (out) 3 pin male XLR (in)
Power: 3 pin IEC
Power: 60 to 250V ±15% @ 50/60Hz.
Consumption: < 30 watts.
Weight: 3.3kg. Net (4.7kg. Shipping)
Size: 1.75"(1U) x 19" x 11.8"
(44 x 482 x 300mm) excluding connectors
 Transformer options available
Due to continuing product improvement the above
specifications are subject to change.
Latency: 1.5mS (analogue in – analogue out @ 96kHz)
