XTA 5 series User Manual

      
            
      
Operator’s Manual Page 55
Setting Accurate Limiter Thresholds
The limiters built into the 5 Series
5 Series5 Series
5 Series are intended to be used for loudspeaker driver protection, as opposed to amplifier
protection. All modern professional power amplifiers designed for live sound use have their own limiters, which are
tailored to protecting the amplifier from clipping.
The following section describes how to set up the units’ limiters to provide exceptional protection against driver
overheating, and cone over-excursion.
Most speaker systems are given a power rating in Watts RMS. This is the maximum continuous power that the system will
handle and often appears very conservative. In reality, as music program is far from continuous in nature, the peak power
of the system is much higher – up to ten times the continuous figure. Any limiter, which is to protect the driver from
damage, must be able to fulfil the following tasks.
• Have an attack time which is calculated to allow transients through but keep the RMS level below the speaker
manufacturers specification;
• Have a release time which is sufficiently long to avoid the limiter itself modulating the program;
• Be intelligent enough to adjust the envelope of the limiter according to the frequency content of the program
material.
The program limiters are capable of performing all these tasks. The only parameter that the user must set manually is the
threshold, and it is crucial that this is done correctly. Consider the table below.
dB
Ratio
Vrms
Pwr 8
Ω
Pwr 4
Ω
Pwr 2
Ω
45
177.83
137.74
2371.71
4743.42
9486.83
44
158.49
122.77
1883.91
3767.83
7535.66
43
141.25
109.41
1496.45
2992.89
5985.79
42
125.89
97.52
1188.67
2377.34
4754.68
41
112.20
86.91
944.19
1888.39
3776.78
40
100.00
77.46
750.00
1500.0
0
3000.00
39
89.13
69.04
595.75
1191.49
2382.98
38
79.43
61.53
473.22
946.44
1892.87
37
70.79
54.84
375.89
751.78
1503.56
36
63.10
48.87
298.58
597.16
1194.32
35
56.23
43.56
237.17
474.34
948.68
34
50.12
38.82
188.39
376.78
753.57
33
44.67
34.60
149
.64
299.29
598.58
32
39.81
30.84
118.87
237.73
475.47
31
35.48
27.48
94.42
188.84
377.68
30
31.62
24.49
75.00
150.00
300.00
Using this table it is a straightforward procedure to work out the required setting of the limiter thresholds for the system.
 First, check the RMS power rating of the speaker system, and its impedance.
 Look up this value in the table above, using the closest value below the rated power of the speaker system. Note
the corresponding ‘dB’ value.
 Check the gain of your amplifier, which needs to be in ‘dB’.
 Subtract this gain figure FROM that obtained from the table to find the required absolute setting for the limiter
thresholds.
Note that, for safety, always set the limiter threshold 1 or 2 dB below the maximum allowable worked out using the above
method.
ALWAYS REFER TO YOUR SPEAKER MANUFACTURER FOR LIMITER SETTINGS.
