DP224/6 Operators Manual Page 35
AES / EBU Sub-Menu
Connection of AES/EBU signals is via the existing rear panel XLR connectors.
With the AES/EBU option fitted, AES Receive and Diagnostic modes are provided.
Routing Options
Selects the input source – either analogue or digital, and similarly the output source,
again either analogue or digital.
AES Diagnostics
Reports validity flag, clock speed and errors present in the incoming AES digital signal.
AES / EBU Connections
The AES/EBU digital signal is a stereo data stream, and so only one input XLR and
three output XLRs are used for the digital interface.
The connections are as follows:
Input A - Analogue Input at all times
Input B - Switchable between digital (stereo) input and analogue input
Output 1 - Switchable between digital out (for channels 1 & 2) and analogue out 1
Output 2 - Switchable between digital out (for channels 3 & 4) and analogue out 2
Output 3 - Switchable between digital out (for channels 5 & 6) and analogue out 3
Output 4 - Analogue output 4 only
Output 5 - Analogue output 5 only
Output 6 - Analogue output 6 only
