DP224/6 Operators Manual Page 43
 First, check the RMS power rating of the speaker system, and its impedance.
 Look up this value in the table above, using the closest value below the rated
power of the speaker system. Note the corresponding ‘dB’ value.
 Check the gain of your amplifier, which needs to be in ‘dB’.
 Subtract this gain figure from the dB value obtained from the table to find the
required absolute setting for the limiter thresholds.
Note that, for safety, always set the limiter threshold 1 or 2 dB below the maximum
allowable worked out using the above method.
ALWAYS REFER TO YOUR SPEAKER MANUFACTURER FOR
LIMITER SETTINGS.
