Out 1 Output 1 HPF
25.8Hz Linkw-Riley 24dB
Bypass PEQ’s 6 & 7
To Access 48dB Slopes
Out 1 Output 1 LPF
9k70Hz Linkw-Riley 24dB
Bypass PEQ’s 8 & 9
To Access 48dB Slopes
Output High Pass Filter
Set the high pass filter frequency — a setting of “<10Hz” bypasses the filter. To change the
filter slope and type, press ENTER and then adjust with the encoder. Note that 48dB/Octave
filters will only be available if PEQ 6 & 7 are bypassed.
Parametric bands will remember their settings if bypassed and used in 48dB/Octave
crossover filters and these settings will be reinstated if a lower order filter type is
subsequently chosen (24dB/Octave or lower).
The message
will be shown if the bands aren’t already in bypass (or set to 0dB).
Output Low Pass Filter
Set the low pass filter frequency — a setting of “>32kHz” bypasses the filter. To change the
filter slope and type, press ENTER and then adjust with the encoder. Note that 48dB/Octave
filters will only be available if PEQ 8 & 9 are bypassed.
Parametric bands will remember their settings if bypassed and used in 48dB/Octave
crossover filters and these settings will be reinstated if a lower order filter type is
subsequently chosen (24dB/Octave or lower).
The message
will be shown if the bands aren’t already in bypass (or set to 0dB).
