1.4 TECHNICAL SPECIFICATIONS
3.0 / 4.0 compatible, + EDR dual mode
Bluetooth indicator, power indicator, vehicle diagnostic
light, light indicator
87.00 * 50.00 * 25.00 mm (3.43 * 1.97 * 0.98 inches)
Table 1-2 Specifications
1.5 WIRELESS COMMUNICATION
Anyscan uses Bluetooth communication. It can transmit vehicle data to your
Android or IOS device without a physical connection. The working range for
Bluetooth is around 10 m (32.81 ft.). Signal lost due to moving out of the range will
automatically be restored once the device is brought within transmission range to
the Anyscan connector.
1.6 POWER SOURCE
Anyscan operates on 12-volts vehicle power which it receives through the vehicle
data connection port. And the real-time operating voltage is shown on the display.
The unit powers on whenever it is connected to an OBDII compliant data link
connector (DLC).
