LCD Display Abbreviaons
Abbreviaon Display content Meaning
ENA Enable
DIS Disable
ATO Auto
BAT Baery
NCF Normal mode (not CVCF mode)
CF CVCF mode
SUB Subtract
ADD Add
ON On
OFF O
FBD Not allowed
OPN Allowed
RES Reserved
O P.V Output voltage
LCD Seng
There are three parameters to set up the UPS. Refer to following diagram.
Parameter 1
Parameter 1: It’s for program alternaves. There are
15 programs to set up. Refer to below table.
Parameter 2 and parameter 3 are the seng opons
or values for each program.
Parameter 2 Parameter 3
