pg | 36
Connect Sonde
Bluetooth
Before users can communicate wirelessly with their EXO sondes, they must establish a Bluetooth link. All
EXO sondes are equipped with Bluetooth wireless. is technology provides a secure, two-way, reliable
communication channel with which users can communicate with their sondes above water without cables.
Many new computers are equipped with Bluetooth wireless installed internally; those without Bluetooth
can use a Bluetooth dongle (not included). Follow the manufacturer’s instructions for installing the dongle’s
soware and hardware. Administrative permissions and IT support may be required depending on the
adapter and your PC settings.
1 Install Bluetooth dongle (optional).
If your computer is not equipped with internal Bluetooth,
insert a Bluetooth dongle (not provided) into any of
the computer’s USB ports. Wait for the computer to
automatically install the device and its drivers. Once the
installation is complete, the computer should indicate that
the device is installed and ready to use.
e preferred Bluetooth conguration is Windows 7 with
native Windows Bluetooth drivers and soware.
2 Activate sonde’s Bluetooth.
Users activate Bluetooth wireless by holding a magnet
at the magnetic activation area. In addition to magnetic
activation, users can also activate Bluetooth by:
• Applying power to the sonde
• Enabling Bluetooth via KOR through a USB or eld
cable connection at the topside port.
See more information on sonde activation and LED
conditions in sections 2.4 and 2.5.
3
a
Establish Bluetooth link. (Win XP)
1.Open Control Panel>Bluetooth Devices.
2.Check “My device is setup and ready to be found,” then
click “Next.”
3.Locate the sonde from the options. e sonde name
should begin with YSI.
4.Select “Use passkey found in documentation,” and enter
the passkey 9876. Click “Next.”
5.Select Finish.
e device is now available in the “Devices” tab.
2 .10
