Flow Cell
ere are two versions of the EXO ow cell: EXO1 ow cell (#599080) and EXO2 ow cell (#599201). Flow
rate of the ow cell is typically between 100 mL and 1 L per minute. Maximum ow rate depends on tubing
type, size, and length. Maximum pressure for each ow cell is 25 psi.
Inspect sonde and flow cell.
Remove the sonde guard or calibration cup from the sonde
so that the sensors are exposed.
Make sure that the threads of the sonde and ow cell as
well as all o-rings are clean and free of any particles such as
sand, grit, or dirt.
Insert sonde into flow cell.
Insert the sonde into the top of the ow cell. Be careful not
to bump or scrape the sensors on the sides of the ow cell.
Screw the sonde into the ow cell by turning the sonde
clockwise until it is hand-tightened into place; do not use
a tool.
Connect tubing to flow cell.
Install the Quick Connect tube ttings onto the ow cell
by inserting them into the Quick Connect coupling body.
ey should snap into place.
Connect the tubing from your pump (not included) to the
Quick Connect tube ttings, making sure that the tubing is
pushed securely onto the ttings. e inow should be at
the bottom of the ow cell and the outow should be at the
top.
Keep ow cell vertical to purge it and ensure air release
from Conductivity/Temperature sensor.
Do not turn on water to the system until the ow cell is
securely connected.
Inflow ..
Outflow ..
