Yale Assure Lock 2 User Manual

35
P/N YRD604-KD-BLE-0047 Rev A
Deadbolt grinds and will not extend to lock
when using an entry code but thumbturn
locks and unlocks smoothly.
· Lock was not handed properly. Find the setting called “Lock Handing” to fix this issue.
Deadbolt is hitting the strike plate. · Reposition the strike plate to align with deadbolt.
Deadbolt is not fully extending. · Increase depth of the deadbolt strike pocket in the frame.
Resistance when locking deadbolt that
requires pushing or pulling on the door to
align deadbolt and latch.
Adjust your existing knob, lever, or handleset strike plate. Latch engagement into the strike is the main
component used for door alignment.
To adjust knob / lever / handleset strike plate:
1. Remove plate from door frame with a hand screwdriver. Note: Using an electric driver may strip
screw heads or enlarge screw holes.
2. Locate tab on strike plate. Bend the tab towards surface of strike. Note: A small change may be all
that is required.
3. Reinstall strike plate using a screwdriver and test again.
4. If door cannot be adjusted sufficiently with strike tab, both knob/lever/handleset latch and deadbolt
could require adjustment – we suggest you contact a local locksmith for assistance.
For help with misalignments, watch our door alignment video: US.YaleHome.com/Support
Hardware Troubleshooting

Yale Assure Lock 2 Specifications

General

Lock Type	Deadbolt
Connectivity	Bluetooth, Wi-Fi (with module)
Power Source	4 AA Batteries
Battery Life	Up to 1 year
Auto-Lock	Yes
Weight	Varies by model
Keypad Type	Touchscreen
Compatibility	Amazon Alexa, Google Assistant, Apple HomeKit
Installation	DIY, fits standard doors
Door Thickness Compatibility	1-3/8" to 2-1/4"
User Codes	Up to 25
Weather Resistance	Weather resistant
Backset	Adjustable 2 3/8" or 2 3/4"
Warranty	1-year on electronic parts
Finish	Satin Nickel, Oil Rubbed Bronze, Black Suede
Backup Power	9V battery terminal
