Yale Assure Lock 2 User Manual

26
18
Door Propped
Timer ³
1 byte
0x00
(Disable) ⁴
0xFE (2540
seconds) ⁴
0x00
(Disable) ⁴
Adjust the time to
receive an alert when
the door is propped
open.
66
19
DPS Alarms
(DoorSense™) ³
1 byte
0x00
(Disable)
0xFF
(Enable)
0xFF
(Enable)
Enable or Disable DPS
Alarms
28
28
Expiring Pin Code
Enabled Time
1 byte
0x00
(Disable)
0xFF (127
Hours)
0x00
(Disable)
Timeout value used to
determine time after
first entry is triggered.
68
¹ Even though the lock accepts value 0x01 for Auto Relock Time, we limit the lock’s minimum to value of 0x03. Therefore, if user tries to set
Auto Relock Time to values 0x01 or 0x02, it will always report back value of 0x03.
² When Operation Mode feature is set to Passage Mode, this also results in disabling the following configuration parameters 2 (Auto Relock
feature). The Passage Mode feature can only be set when user holds the inside button.
³ This requires additional Hardware and calibration within the Yale Access App.
⁴ The Door Propped value is represented as seconds X 10. (i.e., a value of 4 would mean a door propped timer of 40 seconds).

Yale Assure Lock 2 Specifications

General

Lock Type	Deadbolt
Connectivity	Bluetooth, Wi-Fi (with module)
Power Source	4 AA Batteries
Battery Life	Up to 1 year
Auto-Lock	Yes
Weight	Varies by model
Keypad Type	Touchscreen
Compatibility	Amazon Alexa, Google Assistant, Apple HomeKit
Installation	DIY, fits standard doors
Door Thickness Compatibility	1-3/8" to 2-1/4"
User Codes	Up to 25
Weather Resistance	Weather resistant
Backset	Adjustable 2 3/8" or 2 3/4"
Warranty	1-year on electronic parts
Finish	Satin Nickel, Oil Rubbed Bronze, Black Suede
Backup Power	9V battery terminal
