Yale Assure Lock YRL216

27
P/N - - Rev AYRL LPBINSTL FUL
Symptom
Suggested Action
Lock does not respond –
door is open and
accessible.
•
•
•
•
•
•
Unit chimes to indicate
code acceptance, but the
door will not open.
•
•
Unit operates to allow
access, but will not
automatically re-lock.
•
•
•
PIN codes will not register.
•
•
•
•
•
•
Upon entering a codePIN
and pressing key, the
lock gives a series of beeps,
flashes red 7 times, and
does not unlock.
•
•
•
Upon entering a codePIN
and pressing the key,
the lock gives a series of
beeps.
•
•
The unit operates, but it
makes no sound.
•
The unit displays inter-
mittent RED flashes.
•
Upon entering a codePIN
and pressing the key,
the unit responds with a
series of beeps and the
keypad flashes three times.
•
* When batteries are replaced, Network Module locks have a real time clock that will be set
through the User Interface ( ); it is recommended to verify correct date and timeUI
particularly those locks operating under Daylight Saving Time ( ).DST
Lock does not respond –
door is locked and
inaccessible.
•
Unit is on for a while then
shows no reaction. Lights
dim.
PIN codes must consist of 4 to 8 digits to register.
Disable Auto Re-lock Mode to lock the door (automatically).
Check or gear cannot be used as part of the code.PIN
Contact the Master user.
Check that the wire cable is firmly connected to the .PCB
Check the door gaps for any foreign objects between door
and frame.
Batteries may be completely discharged.
Check batteries are installed and oriented correctly (polarity)
in the battery case.
User codes must be entered within 5 seconds or process
will have to be restarted.
Registration/management of codes is set by thePIN
authority of the Master Code, which is set first.
The same code cannot be used for multiple users.PIN
If low battery indicator is lit (see below), change batteries*.
Check to see if Auto Re-lock Mode is enabled.
Batteries do not have enough power. Replace batteries*.
Use mechanical key to gain entry and replace batteries*.
Check to see if touchscreen harness is fully connected
and not pinched.
Check batteries are in good condition; replace batteries*
if discharged.
Press each keypad button for response when pressed.
The digits entered were incorrect or incomplete. Re-enter
the correct code followed by the check key.
This is the alert to replace the batteries. Replace all four
(4) batteries* with new Alkaline batteries.AA
Enable Audio Mode
Setting/managing Lockout Mode is done through
Master Code only. Contact the Master user.
Check to see if the lock is set to Lockout Mode.
Contact the Master user.
Only the Master can enable/disable Lockout Mode.
Lockout Mode is enabled.
Programming Troubleshooting
