10
P/N 80-9150-0080-010 (10-17)
9
Installing Inside Escutcheon
Testing Inside Lever Operation
Avoid pinching
cables
!
Thin door gaskets sold separately.
See Installation Options.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yale nexTouch and is the answer not in the manual?

Yale nexTouch Specifications

General IconGeneral
Power Source4 AA Batteries
Keypad TypeTouchscreen
Auto-LockYes
Backup KeyYes
Finish OptionsSatin Nickel, Oil Rubbed Bronze
Door Thickness1-3/8" to 2-1/4"
Backset2-3/8" or 2-3/4"
ConnectivityNone (standalone)
User CodesUp to 500 (with Z-Wave), 25 (Standalone)
