Yale nexTouch User Manual

2
P/N 80-9150-0080-010 (10-17)
?
Determining Handing
Left Hand “ ”, Hinges Left.LH
Open Inward.
Left Hand Reverse " ", Hinges Left.LHR
Open Outward.
Right Hand " ", Hinges Right.RH
Open Inward.
Right Hand Reverse " ", Hinges Right.RHR
Open Outward.
The hand of a door is determined from the secure side of the door. The
term "secure" means the side from which you initially unlock and enter.

Yale nexTouch Specifications

General

Power Source	4 AA Batteries
Keypad Type	Touchscreen
Auto-Lock	Yes
Backup Key	Yes
Finish Options	Satin Nickel, Oil Rubbed Bronze
Door Thickness	1-3/8" to 2-1/4"
Backset	2-3/8" or 2-3/4"
Connectivity	None (standalone)
User Codes	Up to 500 (with Z-Wave), 25 (Standalone)
