3
P/N 80-9150-0080-010 (10-17)
Preparing Door
!
Drill holes 1/2 way thru
door then complete from
other side to prevent
splitting.
DPS Option
Wood Door:
3/8" Dia. x Thru to
Hole in Door Face
*Metal Door:
3/4" Dia. Thru to
Hole in Door Face
*Metal Door Installations
Supplied plastic collar beMUST
installed for to function properly.DPS
80-8150-0032-010
Rev C
nexTouch
™
Cylindrical Lock
BEVELED EDGE
DOOR ONLY
HIGH EDGE
LOW EDGE
aaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaa
1" Dia.(25mm)
Thru Door
HIG H ED GE Fold Line
2-3/4" Beveled Backset
2-3/8" Square Backset
Fold Line
2-3/8" Square Backset
Fold Line
5/32" Dia x 1/8" Deep
(4mm x 3mm)
2 Locations
Both sides of door
2-3/4" (70mm)
Between Centers
2-1/8" Dia
(54mm)
Thru Door
3-1/2"
(89mm)
Between
Centers
3"
3"
CAUTION:
If printed from website
Print 1:1 Scale
Measure both 3" lines to check scale
aaaaaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaaaaaaaa
SQUARE EDGE
DOOR ONLY
5/32" Dia x 1/8" Deep
(4mm x 3mm)
2 Locations
Both sides of door
HIG H ED GE Fold Line
2-3/8" Beveled Backset
LOW EDG E Fold Line
2-3/8" Beveled Backset
LOW EDG E Fold Line
2-3/4" Beveled Backset
WHEN IN TOP
POSITION ONLY
5/16" Dia
(8mm)
Thru Door
5/16" Dia
(8mm)
Thru Door
1" Dia.(25mm)
Thru Door
WHEN IN TOP
POSITION ONLY
3-1/2"
(89mm)
Between
Centers
Horizontal
Center Line
Vertical
Center Line
CUT
CUT
CUT CUT
CUT
CUT
Product Support Tel 800-810- (9473) • www.yalelocks.comWIRE
nexTouch™ is a trademark of Yale Security Inc., an ASSA ABLOY Group company.
ASSA ABLOYCopyright © 2017, Yale Security Inc., an Group company.All rights reser ved.
Reproduction in whole or in part without the express written permission of Yale Security Inc., an Group company is prohibited.ASSA ABLOY
Yale Locks & Hardware is a division of Yale Security Inc., an Group company.ASSA ABLOY
An ASSA ABLOY Group brand
3/4" (19mm) Dia.
Metal Frame
3/8" (9.5mm) Dia.
Wood Frame
nexTouch Cylindrical Locks
™
NTB610
620NTB
630NTB
640NTB
Cylinder Override - Push Button
Cylinder Override - Cap Touch
No Cylinder Override - Push Button
No Cylinder Override - Cap Touch
3/4" (19mm) Dia.
Metal Frame
3/8" (9.5mm) Dia.
Wood Frame
1
!
