Hardware Troubleshooting
Cycle lock in both the locked and unlocked positions. If problems are found:
Latchbolt will not deadlock.
a. Either strike is out of alignment or the gap between door and jamb is too great.
Realign strike or shim strike out towards flat area of latchbolt.
Latchbolt does not retract or extend properly.
Latchbolt tail and retractor are not properly positioned:
a. Remove lockset. Look through 2-1/8" hole and verify latchbolt tail is centered
between top and bottom of hole.
b. Remove latchbolt and insert lockset. Look through latchbolt hole and verify retractor
mouth is centered in hole. If not, adjust outside rose plate.
c. If necessary, rebore holes to line up retractor and tail.
Door is binding.
Factory Settings
Settings
Factory Setting
Master CodePIN
Registration
required*
Automatic Relock
5 Seconds
One Touch Locking
Enabled
Privacy Setting Disabled
Language
English
Wrong Code Entry Limit
5 Times
Shutdown Time 60 Seconds
*The Master code must be registered prior to any otherPIN
programming of the lock.
Volume Setting High
All Code Lockout Mode
Disabled
