Curved edge of latchbolt
faces direction door closes.
!
Installing Latchbolt
Inside of Door
7-16 / 8-32 x 1" UNCWS
x2
Removing Battery Cover
4
5
2-3/8" Latchbolt for thin doors sold separately.
See Installation Options.
