Yale nexTouch

4
P/N 80-9150-0080-010 (10-17)
2
Preparing Frame
DoorFrame
1" Dia. x
1/2" Deep
Frame
DPS Option
Wood Frame:
3/8" Dia. x 1"
*Metal Frame:
3/4" Dia. x 1"
See Instruction
A7983B
Inside
of Door
Frame
3-1/2"
7-16 / 8-32 x 1" UNCWS
x2
*Metal Frame Installations
Supplied plastic collar beMUST
installed for to function properly.DPS
!
