Controls and Connections 5
02R User’s Guide
11. MIXING buttons
These buttons access the corresponding Display function.
12. AUX buttons
These buttons access the corresponding Display function.
Button Description
∅/ATT Set phase and attenuation.
DELAY Set the channel delay.
PAN Set the pan position.
ROUTING Set the channel routing.
METER Meter the levels from the individual input
channels, the tape and effect return chan-
nels, the 8 main busses, and the 8 auxiliary
busses.
VIEW View and set all the parameters for the se-
lected channel and access the channel li-
brary.
EQ Set the equalization and access the EQ li-
brary.
DYNAMICS Set the dynamics and access the dynamics
library.
Button Description
AUX 1 to 6 Set the channel levels to the auxiliary bus-
ses.
AUX 7 and 8 Set the channel levels to the auxiliary bus-
ses and set the effect parameters.
