Yamaha 02R Version 2 - Display Functions

22 User Interface
02R User’s Guide
Display Functions
The following table lists all the 02R display functions and briefly explains
what they do.
Display Function Description
SCENE Store and recall mix scenes.
DIGITAL I/O Sets digital I/O parameters and selects word
clock.
SETUP Sets the solo parameters and system prefer-
ences.
UTILITY Controls the oscillator parameters and access-
es the emphasis monitor, the channel status
monitor, and the battery level check.
MIDI Set the MIDI channels, build the program
change table, and control MIDI bulk data trans-
fers.
AUTOMIX Create, store, recall, and play automix programs.
GROUP Set up the fader and mute groups.
PAIR Set up channel pairs.
∅/ATT Set phase and attenuation.
DELAY Set the channel delay.
PAN Set the pan position.
ROUTING Set the channel routing.
METER Meter the levels from the individual input chan-
nels, the tape and effect return channels, the 8
main busses, and the 8 auxiliary busses.
VIEW Set all parameters for the selected channel
and access the channel library.
EQ Set the equalization and access the EQ library.
DYNAMICS Set the dynamics processor and access the
dynamics library.
AUX 1 to 6 Set the channel levels to the auxiliary busses.
AUX 7 and 8 Set the channel levels to the auxiliary busses
and set the internal effect parameters.
