Yamaha 02R Version 2 - General Specifications; General Specifications

240 Specifications
02R User’s Guide
Specifications
General Specifications
* Hum & Noise are measured with a 6 dB/octave filter @12.7 kHz; equivalent to a 20 kHz filter with an infinite dB/oc-
tave attenuation.
* Sampling Frequency: Internal 48 kHz
Number of scene memories 96
Sampling frequency
Internal 44.1 kHz, 48 kHz
External (32 kHz –6%) to (48 kHz +6%)
Signal delay Less than 2.5 ms. MIC/LINE input to STEREO output
Fader resolution
+10 to –90, –∞ dB (128 steps/100 mm) input faders.
0 to –120, –∞ dB (128 steps/100 mm) stereo fader
Total harmonic distortion (THD) Less then 0.2%, 20 Hz to 20 kHz (analog output) @+14 dB into 600Ω
Frequency response +1, –3 dB, 20 Hz to 20 kHz @+4 dB into 600Ω
Dynamic range
110 dB typical D/A Converter (STEREO OUT) *
105 dB typical A/D to D/A (MIC/LINE IN to STEREO OUT) *
Hum & Noise (20 Hz to 20 kHz) *,
Rs = 150Ω, Input gain max.
Input pad = 0 dB
Input sensitivity = –60 dBV
–128 dB Equivalent input noise
–88 dB residual output noise. STEREO OUTPUT. STEREO OUT-
PUT off
–88 dB (92 dB S/N) STEREO OUTPUT. Master fader at nominal lev-
el and all channel faders at minimum level
–64 dB (68 dB S/N) STEREO OUTPUT. Master fader at nominal lev-
el and one input fader at nominal level
Maximum Voltage Gain
74 dB MIC/LINE (1 through 16) IN to STEREO OUT
74 dB MIC/LINE (1 through 16) IN to AUX SEND 1, 2, 3, 4, 5, 6 (via
PRE INPUT FADER)
74 dB MIC/LINE (1 through 16) IN to MONITOR OUT (via STEREO
bus)
54 dB LINE (17 through 24) IN to STEREO OUT
Crosstalk(@1kHZ)
70 dB adjacent input channels
70 dB input to output
Specifications
