100 Auxiliary Channels
02R User’s Guide
Select a channel with the [SEL] buttons. Select the auxiliary bus with the
[AUX 1] through [AUX 8/EFF 2] buttons. Turn the send on or off with the
[ON] button. Adjust the send level with the SEND LEVEL encoder.
AUX Pages
The channel aux send level controls for each aux send are displayed on two
pages. The first page, shown below, shows aux controls for MIC/LINE
channels 1 to 24. Select this page using a MIC/LINE [SEL] button.
The second page shows aux controls for TAPE channels 1 to 16 and effects
returns 1 and 2. Select this page using a TAPE or EFF RTN [SEL] button.
SEND LEVEL
