Installing Options 237
02R User’s Guide
4. PEAK HOLD button
This button is used to enable or cancel the Peak Hold function.
5. STEREO-BUS-AUX Indicators
These indicators show the meter source points for the channels being
monitored.
• PRE FADER—When this LED is illuminated, the bus signal
before the fader is being displayed.
• POST FADER—When this LED is illuminated, the bus signal
after the fader is being displayed.
The meter source points are set with the METER display function. See
“Meter Source Points” on page 42 of the User’s Guide.
6. MIC-LINE-TAPE Indicators
These indicators show the meter source points for the channels being
monitored.
• PRE EQ—When this LED is illuminated, the signal before the EQ
signal is being displayed.
• POST EQ—When this LED is illuminated, the signal after the EQ
is being displayed.
• POST FADER—When this LED is illuminated, the signal after
the fader is being displayed.
The meter source points are set with the METER display function. See
“Meter Source Points” on page 42 of the User’s Guide.
Note: The operation of this button duplicates the function of the PEAK
HOLD icon in the METER display function. See “Metering” on page 41 and
“Peak Hold” on page 42 of the User’s Guide.
