Yamaha 02R Version 2 - Page 364

268 Appendix: MIDI
02R User’s Guide
PARAMETER CHANGE (key remote)
STATUS 11110000 F0 System Exclusive Message
ID No. 01000011 43 Manufacturer's ID No.(YAMAHA)
SUB STATUS 0001nnnn 1n n=0-15(Tx/Rx Channel No.1-16)
MODEL ID 00111101 3d MODEL ID (02R)
PARAM TYPE 00011001 19 key remote (type number)
DATA 0ddddddd dd0 key No.( H) high 7 bits
0ddddddd dd1 key No.( L) low 7 bits
0ddddddd dd2 key on( 1)/off( 0)
EOX 11110111 F7 End Of Exclusive
PARAMETER CHANGE (fader remote)
STATUS 11110000 F0 System Exclusive Message
ID No. 01000011 43 Manufacturer's ID No.(YAMAHA)
SUB STATUS 0001nnnn 1n n=0-15(Tx/Rx Channel No.1-16)
MODEL ID 00111101 3d MODEL ID (02R)
PARAM TYPE 00011001 1A fader remote (type number)
DATA 0ddddddd dd0 No. (0-20:fader 1-21(st mas)
64-87:encoder tape1-16,rtn1-2,aux,pan,q,f,g,entry)
0ddddddd dd1 data(fader 0~127/ encoder -64~+63)
EOX 11110111 F7 End Of Exclusive
