274 Appendix: MIDI
02R User’s Guide
Scene Memory(Extended Data)
STATUS 11110000 F0 System Exclusive Message
ID No. 01000011 43 Manufacturer's ID No.(YAMAHA)
SUB STATUS 0000nnnn 1n n=0-15(Tx/Rx Channel No.1-16)
FORMAT NO. 01111110 7E Universal Bulk Dump
BYTE COUNT(H) 00001100 0C Total 1546(768*2+10)
BYTE COUNT(L) 00001010 0A
01001100 4C 'L'
01001101 4D 'M'
00100000 20 ' '
00100000 20 ' '
00111000 38 '8'
01000001 41 'A'
00110110 36 '6'
00110111 37 '7'
DATA NAME 01001110 4E 'N'
0mmmmmmm mm mm=0-96,127(Scene Memory No.0-96,Current)
DATA 0ddddddd dsH Scene Extended Memory(768*2 byte)
0ddddddd dsL
:
0ddddddd deH
0ddddddd deL
CHECK SUM 0eeeeeee ee ee=(INVERT('L'+'M'+...+deL)+1) AND 7Fh
EOX 11110111 F7 End Of Exclusive
Control Change Assign Table
STATUS 11110000 F0 System Exclusive Message
ID No. 01000011 43 Manufacturer's ID No.(YAMAHA)
SUB STATUS 0000nnnn 1n n=0-15(Tx/Rx Channel No.1-16)
FORMAT NO. 01111110 7E Universal Bulk Dump
BYTE COUNT(H) 00000100 03 Total 466(228*2+10)
BYTE COUNT(L) 01001010 52
01001100 4C 'L'
01001101 4D 'M'
00100000 20 ' '
00100000 20 ' '
00111000 38 '8'
01000001 41 'A'
