Yamaha 02R Version 2 - Page 380

284 Appendix: MIDI
02R User’s Guide
BYTE COUNT
(HIGH/LOW)
00000000 00
122(48x2+16+10)bytes
01111010 7A
01001100 4C 'L'
01001101 4D 'M'
00100000 20 ' '
00100000 20 ' '
00111000 38 '8'
01000001 41 'A'
00110110 36 '6'
00110111 37 '7'
DATA NAME
01001000 48 'H'
0mmmmmmm mm m=0–63(Channel Library No.1–64)
DATA
0ttttttt tt title1
: : :
0ttttttt tt title16
0ddddddd dsH
Channel Library Memory(48x2bytes)
0ddddddd dsL
: :
0ddddddd deH
0ddddddd deL
CHECK SUM 0eeeeeee ee ee=(INVERT('L'+'M'+...+dsH+...+deL)+1) AND 7Fh
EOX 11110111 F7 End Of Exclusive
Channel Library(Extended Data)
STATUS 11110000 F0 System Exclusive Message
ID No. 01000011 43 Manufacturer's ID No.(YAMAHA)
SUB STATUS 0000nnnn 1n n=0-15(Tx/Rx Channel No.1-16)
FORMAT NO. 01111110 7E Universal Bulk Dump
BYTE COUNT(H) 00000000 00 Total 38(14*2+10)
BYTE COUNT(L) 00100110 26
01001100 4C 'L'
01001101 4D 'M'
00100000 20 ' '
00100000 20 ' '
00111000 38 '8'
01000001 41 'A'
00110110 36 '6'
00110111 37 '7'
Channel Library Bulk Dump Format
