286 Appendix: MIDI
02R User’s Guide
01001100 4C 'L'
01001101 4D 'M'
00100000 20 ' '
00100000 20 ' '
00111000 38 '8'
01000001 41 'A'
00110110 36 '6'
00110111 37 '7'
DATA NAME
01000001 41 'A'
0000mmmm 0m m=0–15(Automix No.1–16)
DATA
0xxxxxxx xx block count( High)
0xxxxxxx xx block count( Low) [ 0~size]
0yyyyyyy yy total size( High)
0yyyyyyy yy total size( Low)[ size–1]
0ttttttt tt title1
: : :
0ttttttt tt title16
0ddddddd dsH
Automix Memory(1024x2bytes)
0ddddddd dsL
: :
0ddddddd deH
0ddddddd deL
CHECK SUM 0eeeeeee ee ee=(INVERT('L'+'M'+...+dsH+...+deL)+1) AND 7Fh
EOX 11110111 F7 End Of Exclusive
Automix (compact)
STATUS 11110000 F0 System Exclusive Message
ID No. 01000011 43 Manufacturer's ID No.(YAMAHA)
SUB STATUS 0000nnnn 1n n=0-15(Tx/Rx Channel No.1-16)
FORMAT NO. 01111110 7E Universal Bulk Dump
BYTE COUNT(H) 00010000 10 Total 2078(1024*2+20+10)
BYTE COUNT(L) 00011110 1E
01001100 4C 'L'
01001101 4D 'M'
00100000 20 ' '
00100000 20 ' '
00111000 38 '8'
01000001 41 'A'
Automix Bulk Dump Format
