Editing Events Off-line 195
03D—Owner’s Manual
MTC Time Base Event List Example
MIDI Clock Time Base Event List Example
Time Event Channel Description
--:--:--.-- RCL SAFE OFF Ch 1 Channel 1 scene recall safe set to OFF (normally in list)
--:--:--.-- RCL SAFE OFF Ch 2 Channel 2 scene recall safe set to OFF (normally in list)
::::
--:--:--.-- RCL SAFE ON MasST Stereo output scene recall safe set to ON (normally in list)
--:--:--.-- SAFE ENA. DIS Scene recall safe disable, enable
--:--:--.-- SAFE MODE ALL Scane recall all safe or only fader safe
--:--:--.-- SCENE RCL 0
First mix scene (0) recalled (normally in list). Can be set to
OFF
Dynamic automix data starts here
00:00:10.00 FAD CH 0.2 Ch 1 Channel 1 fader level set to 0.2 dB
00:00:10.04 FAD EFF1 -0.5 Ch18 Channel 18 effects 1 send fader level set to –0.5dB
00:00:10.08 FAD AUX4 1.2 Rtn1 Effects return channel 1 aux 4 send fader level set to 1.2 dB
00:00:10.20 CH ON/OFF OFF Bus2 Bus 2 ON/OFF set to OFF
00:00:10.21 PAN L16 Ch 1 Channel 1 pan set to L16
00:00:10.25 BALANCE C StIn Stereo input channel balance set to center
00:00:10.27 SurPAN LR L16 Ch 1 Channel 1 surround pan left:right set to L16
00:00:11.27 SurPAN FR R16 Ch 1 Channel 1 surround pan front:rear set to R16
00:00:12.27 EQ ON/OFF OFF Ch 1 Channel 1 EQ ON/OFF set to OFF
00:00:12.28 EQ F LOW 4 Ch 1 Channel 1 low EQ frequency set to 4 (see page 196)
00:00:13.10 EQ G L-M 5 Ch 1 Channel 1 low mid EQ gain set to 5 (see page 197)
00:00:13.22 EQ Q H-M 6 Ch 1 Channel 1 high mid EQ set to 6 (see page 197)
00:00:14.04 EQ Q HIGH 7 Ch 1 Channel 1 high EQ Q set to 7 (see page 197)
00:00:14.16 EQ LIB 1 Ch 1 EQ program 1 recalled to channel 1
00:00:14.17 DYNA LIB 1 Ch 1 Dynamics program 1 recalled to channel 1
00:00:14.18 CH LIB 1 Ch 1 Channel program 1 recalled to channel 1
00:00:14.19 RCL SAFE ON Ch 1 Channel 1 recall safe set to ON
00:00:14.20 SCENE RCL 10 Mix scene 10 recalled
00:00:14.21 EFF1 LIB 1 Effects program 1 recalled to Effect 1
00:00:14.22 XF t=3.0s 0.2 Ch 1 Channel 1 cross fade of 3.0 seconds with final level of 0.2 dB
00:00:14.22 PGM MIDI 3 1 Program Change 3 message transmitted on MIDI Channel 1
00:00:14.22 PGM HOST1 4 2 Program Change 4 message transmitted on TO HOST port 1
Time Event Channel Description
--:--:--.-- RCL SAFE OFF Ch 1 Channel 1 scene recall safe set to OFF (normally in list)
--:--:--.-- RCL SAFE OFF Ch 2 Channel 2 scene recall safe set to OFF (normally in list)
::::
--:--:--.-- RCL SAFE ON MasST Stereo output scene recall safe set to ON (normally in list)
--:--:--.-- SCENE RCL 0
First mix scene (0) recalled (normally in list). Can be set to
OFF
----.--.-- SIG.INI 4/4 Initial time signature set to 4/4 (normally in list)
0017.--.-- SIG. 1 3/4
Time signature set to 3/4 (normally in list). Measure can also
be set
::
----.--.-- SIG.12 ----
Time signature change events with no value specified look
like this
Dynamic automix data starts here
0001.01.01 FAD CH 0 Ch 1 Channel 1 fader level set to 0dB
0001.02.01 CH ON/OFF OFF Bus2 Bus 2 ON/OFF set to OFF
Same as MTC Time Base Event List Example on page 195
