208 Chapter 19—Pro Tools Remote Layer
DM2000—Owner’s Manual
Flip Mode
In Flip mode, the faders, Encoders, and [ON] buttons can be used to control sends, as
shown in the following table.
1 Press the FADER MODE [FADER] or [AUX/MTRX] button.
The FADER MODE [FADER] and [AUX/MTRX] button indicators flash alternately, and
both the ENCODER MODE [PAN] (PAN) and [AUX/MTRX] (SEND LEVEL) button
indicators light up. The SELECT ASSIGN section of the display shows “FLIP.”
2 Use the AUX SELECT [AUX 1–5] (SEND A–E) buttons to select the sends.
The button indicator of the selected send lights up.
3 Use the faders, Encoders, and [ON] buttons to control the currently selected
send.
For stereo aux input channels (i.e., channels with two send panpots), use the ENCODER
MODE [PAN] (PAN) button to toggle between the left and right panpots, and pan with the
Encoder. When the left panpot is active, the ENCODER MODE [PAN] (PAN) button indi-
cator is lit continuously. When the right panpot is active, the ENCODER MODE [PAN]
(PAN) button indicator flashes.
Control Normal mode Flip mode
Fader Channel level Send level
Encoder Channel pan/send level Send pan
[ON] button Channel mute Send mute
