MB2000 Peak Meter Bridge 333
DM2000—Owner’s Manual
Appendix D: Options
MB2000 Peak Meter Bridge
Installation
1 Attach the brackets to the meter bridge.
2 Screw the four fixing screws into the DM2000, but don’t tighten them fully.
3 Align the meter bridge with the four screws, and then tighten the screws.
4 Connect the meter bridge cable to the DM2000’s METER port.
To Next Page
