Selecting Encoder Modes
The exact function of each Encoder depends on the selected Layer and Encoder
mode. There are two preset Encoder modes, Pan and Aux/Mtrx, and four assign-
able modes, for which you can choose from over 40 parameters.
1 Select a Layer, as explained in page 42.
2 Use the ENCODER MODE buttons to select
an Encoder mode.
[PAN]: Encoders function as Pan controls.
[AUX/MTRX]: Encoders control Aux or Matrix
Send levels, depending on the selected Layer.
[ASSIGN 1–4]: Encoders control the parameters
assigned to the ASSIGN buttons. See “Assigning
Parameters to the ENCODER MODE Assign Buttons” on page 46 for more information.
The indicator of the currently selected ENCODER MODE button lights up.
The following table shows the exact Encoder functions for each Layer and Encoder mode.
The values of the parameters being controlled by the Encoders are displayed graphically by
the channel strip displays. See “Channel Strip Displays” on page 39 for more information.
Layer
Encoder
Mode
Encoder
1–8 9–16 17–20 21–24
1-24
Pan
CH 1–24: pan
Aux/Mtrx
CH 1–24: Aux Send level
Assign 1–4
CH 1–24: assigned parameter
25–48
Pan
CH 25–48: pan
Aux/Mtrx
CH 25–48: Aux Send level
Assign 1–4
CH 25–48: assigned parameter
49–72
Pan
CH 49–72: pan
Aux/Mtrx
CH 49–72: Aux Send level
Assign 1–4
CH 49–72: assigned parameter
73–96
Pan
CH 73–96 pan
Aux/Mtrx
CH 73–96: Aux Send level
Assign 1–4
CH 73–96: assigned parameter
Master
Pan
No operation No operation
Matrix
1–4: Bal-
ance
Aux/Mtrx
Bus Out 1–8: Matrix
Send level
Aux Send 1–12: Matrix Send level
No opera-
tion
Assign 1–4
Bus Out 1–8: assigned
parameter
Aux Send 1–12: assigned parameter
Matrix
Send 1–4:
assigned
parameter
Remote
1–4
Pan
Operation depends on the selected target. See “About Remote Layers” on
page 217 for more information.
Aux/Mtrx
Assign 1–4
AUX / MTRX PAN
ASSIGN 4ASSIGN 3
DISPLAY
ASSIGN 2ASSIGN 1
PAN SEND LEVEL
INSERTSEND ASSIGNOUTPUTINPUT
ENCODER MODE
