Yamaha DSP-A595a Service Manual

62
DSP-A595a
Schm
Ref
PART NO. Description
✻ New Parts
✻ New Parts
Schm
Ref
PART NO. Description
P. C. B. INPUT & P. C. B. OPERATION
PJ352 VY667700 JACK.PIN 1P
Q101 iC287820 TR 2SC2878 A,B
R141 HV755100 R.CAR.FP 100Ω 1/4W
R154 HV755100 R.CAR.FP 100Ω 1/4W
R155 HV753220 R.CAR.FP 2.2Ω 1/4W
R156 HV753220 R.CAR.FP 2.2Ω 1/4W
R214 HV753220 R.CAR.FP 2.2Ω 1/4W
R215 HV753220 R.CAR.FP 2.2Ω 1/4W
R216 HV753220 R.CAR.FP 2.2Ω 1/4W
R217 HV753220 R.CAR.FP 2.2Ω 1/4W
R231 HV753220 R.CAR.FP 2.2Ω 1/4W
R232 HV753220 R.CAR.FP 2.2Ω 1/4W
R373 HV753220 R.CAR.FP 2.2Ω 1/4W
R411 HV754100 R.CAR.FP 10Ω 1/4W
R412 HV754100 R.CAR.FP 10Ω 1/4W
R435 HV754100 R.CAR.FP 10Ω 1/4W
VR401 VV613500 VR A100KΩ
V4036800 P.C.B. OPERATION(RT)
V4036900 P.C.B. OPERATION(B)
V4037000 P.C.B. OPERATION(G)
CB451 VK026700 CN.BS.PIN 8P
CB800 VU272900 CN 29P
CB802 Vi878900 CN.BS.PIN 11P
CB803 Vi878700 CN.BS.PIN 9P
CB804 VP206500 HOLDER.FUSEYF-52BC(RT)
CB805 VP206500 HOLDER.FUSEYF-52BC(RT)
CB806 Vi878200 CN.BS.PIN 4P
CB807 VK025100 CN.BS.PIN 7P
CB810 VP206500 HOLDER.FUSEYF-52BC(G)
CB811 VP206500 HOLDER.FUSEYF-52BC(G)
CB812 VG879900 CN.BS.PIN 2P
CB813 VP206500 HOLDER.FUSEYF-52BC
CB814 VP206500 HOLDER.FUSEYF-52BC
C451 UR868330 C.EL 330uF 50V
C452 UR868330 C.EL 330uF 50V
C453 UR749680 C.EL 6800uF 25V
C454 VE326400 C.MYLAR.ML 0.22uF 50V
C455 UR749220 C.EL 2200uF 25V
C456 VE326400 C.MYLAR.ML 0.22uF 50V
C457 VS745400 C.POL.MTL 0.1uF 100V
C458 UR73A100 C.EL 10000uF 16V
C459 VJ599100 C.CE.TUBLR 0.1uF 50V
C460 VJ599100 C.CE.TUBLR 0.1uF 50V
C461 VE326400 C.MYLAR.ML 0.22uF 50V
C462 VE326400 C.MYLAR.ML 0.22uF 50V
C800 UR866220 C.EL 2.2uF 50V
C801 VG278900 C.CE.TUBLR 680pF 50V
C802 VG278900 C.CE.TUBLR 680pF 50V
C803 VJ599100 C.CE.TUBLR 0.1uF 50V
C804 UR866100 C.EL 1uF 50V
C805 VJ599100 C.CE.TUBLR 0.1uF 50V
C806 UR819100 C.EL 1000uF 6.3V
C807 UR819100 C.EL 1000uF 6.3V
C808 VU545000 C.EL 47000uF 5.5V
C809 VJ599100 C.CE.TUBLR 0.1uF 50V
C810 UR837100 C.EL 10uF 16V
C811 UR866220 C.EL 2.2uF 50V
C812 VJ599100 C.CE.TUBLR 0.1uF 50V
C813 UR838330 C.EL 330uF 16V
C814 UR838330 C.EL 330uF 16V
C817 UR866100 C.EL 1uF 50V
C818 UR866220 C.EL 2.2uF 50V
C819 UR866220 C.EL 2.2uF 50V
C821 UR866100 C.EL 1uF 50V
C823 VJ599100 C.CE.TUBLR 0.1uF 50V
C824 VJ599100 C.CE.TUBLR 0.1uF 50V
C825 VJ599100 C.CE.TUBLR 0.1uF 50V
C826 UR848220 C.EL 220uF 25V(RT)
C826 UR848330 C.EL 330uF 25V(BG)
C827 UR837470 C.EL 47uF 16V
C828 UA655120 C.MYLAR 0.12uF 50V
C829 VK533800 C.PP 47pF 200V
C830 VK533800 C.PP 47pF 200V
C831 UA655120 C.MYLAR 0.12uF 50V
C832 UR837470 C.EL 47uF 16V
C833 VF466800 C.CE.TUBLR 100pF 50V
C834 VF466800 C.CE.TUBLR 100pF 50V
C835 FG613100 C.CE 1000pF 50V(RT)
C836 UR896470 C.EL 4.7uF 100V(RT)
C837 Vi716700 C.MYLAR 0.01uF 50V
C838 UR847100 C.EL 10uF 25V
C839 UA954330 C.MYLAR 0.033uF 50V
C840 UA954330 C.MYLAR 0.033uF 50V
C841 UR847100 C.EL 10uF 25V
C842 UA954100 C.MYLAR 0.01uF 50V
C843 UR847100 C.EL 10uF 25V
C844 VQ645600 C.MYLAR 100pF 50V
C845 VQ645600 C.MYLAR 100pF 50V
C846 UR847100 C.EL 10uF 25V
C847 VS741700 C.CE.SAFTY 0.01uF 275V
D451 VR253700 DIODE.BRG S1NB20 1.0A 200V
D452 VR253700 DIODE.BRG S1NB20 1.0A 200V
D453 VR253700 DIODE.BRG S1NB20 1.0A 200V
D800 VD631600 DIODE 1SS133,176,HSS104
D801 VD631600 DIODE 1SS133,176,HSS104
D802 VM974100 DIODE.ZENR HZS5B2TD 5.0V
D803 VD631600 DIODE 1SS133,176,HSS104
D805 VD631600 DIODE 1SS133,176,HSS104
D806 VD631600 DIODE 1SS133,176,HSS104
D807 VM974100 DIODE.ZENR HZS5B2TD 5.0V
D808 VM974700 DIODE.ZENR HZS7B2TD 7.0V
D809 VD631600 DIODE 1SS133,176,HSS104
✻
✻
✻
!
!
!
!
!
!
!
