DSP-AX1/RX-V1
DSP-AX1/RX-V1
36
Step
6
7
8
9
10
11
12
Adjustment item
Adjustment of
front end IFT
Verification of monau-
ral distortion
Verification of stereo
distortion
Verification of sensi-
tivity
Adjustment of
Separation
Adjustment of Signal
meter
Verification of auto
tuning
Reception
frequency
98.1MHz
* (A-4)
98.1MHz
* (A-4)
98.1MHz
* (A-4)
*Tuning
mode
should be
AUTO.
88.1MHz
* (A-6)
98.1MHz
* (A-4)
106.1MHz
* (A-7)
98.1MHz
* (A-4)
98.1MHz
* (A-4)
98.1MHz
Signal (ANT IN)
FM ANT (75Ω)
98.1MHz ± 5kHz
30dBµ
MONO
1kHz,
100% modulation
FM ANT (75Ω)
98.1MHz
70dBµ
MONO 1kHz,
100% modulation
FM ANT (75Ω)
98.1MHz
70dBµ
Stereo L or R
1kHz,
100% modulation
FM ANT (75Ω)
88.1MHz
98.1MHz
106.1MHz
MONO 1kHz
100% modulation
FM ANT (75Ω)
98.1MHz
70dBµ
Stereo L or R
1kHz,
100% modulation
FM ANT (75Ω)
98.1MHz
45dBµ
MONO 1kHz
30% modulation
–10dBµ or less
FM ANT (75Ω)
98.1MHz
26dBµ
Stereo L or R
1kHz,
30% modulation
Adjusted
point
Front end IFT
VR2
VR1
Test point
Pin 16 of IC1
REC OUT L, R
REC OUT L, R
ANT (75Ω)
REC OUT L, R
*:Execution of PRESET (Refer to page 27.) will facilitate setting reception frequency for adjustment.
Rating
Adjust so that the DC voltage
is maximum.
CAUTION : Over-adjustment
of the IFT core will reduce the
sensitivity.
Maximum ±90°
0.4% or less
1% or less
• STEREO indicator should
light.
1)Set the tuning mode to
MAN’L MONO.
(Muting OFF)
2) S/N should be 30dB at each
frequency of 88.1MHz,
98.1MHz, and 106.1MHz.
3)Check to ensure that the
voltage at the ANT terminal
is 5dBµ or less.
(A only : 7dBµ or less)
With SSG output at L or R, the
signal leakage level at the
other channel should be mini-
mized.
35dB or more
Adjust so that all segments
light.
Check to ensure that signal
meters turn OFF.
• Automatic reception
should be available when
the tuning key is moved UP
and DOWN.
• The stereo indicator should
light.
• Audio muting should be ap-
plied during tuning.
To Next Page
