RX-V340/RX-V340RDS/HTR-5630/HTR-5630RDS/DSP-AX340
29
RX-V340/RX-V340RDS/
HTR-5630/HTR-5630RDS/DSP-AX340
THM/Fan (temperature detection/fan drive level)
THM: 500% display of the voltage based on the
temperature detected value. Reference voltage :
5V (Normal value: 30 to 147)
Fan: Current fan drive level on the left and the past fan
drive history on the right.
(Not applied to these models.)
THM/Fan
10. AD DATA CHECK/FAN TEST
This menu is used to display the A/D conversion value of
the terminals which detects panel keys of the main unit
and protection functions in % using the sub-menu. During
signal processing, the condition before execution is
maintained.
When K0/K1 menu is selected, keys become non-
operable due to detection of the values of all keys.
However, it is possible to advance to the next sub-menu
by turning the VOLUME of the main unit. When using this
function, note that turning the VOLUME more than 2 clicks
will cause the volume value to change.
* The figures in the diagram are given as reference only.
STATION FM FACTORY PRESET DATA (MHz)
PAGE NO. U, C R, T, K, A, B, G, L J
1 87.5 87.5 76.0
2 90.1 90.1 83.0
3 95.1 95.1 84.0
A/C/E
4 98.1 98.1 86.0
5 107.9 108.0 90.0
6 88.1 88.1 78.0
7 106.1 106.1 88.0
8 107.9 108.0 82.1
STATION AM FACTORY PRESET DATA (kHz)
PAGE NO. U, C, R, T, K A, B, G, L J
1 630 630 630
2 1080 1080 1080
3 1440 1440 1440
B/D
4 530 531 531
5 1710 1611 1611
6 900 900 900
7 1350 1350 1350
8 1400 1404 1404
• PRESET STATIONS / プリセット局
10.ADDATACHECK/FANTEST
DC/PS
DC/PS (protection detection)
DC: DC protection value (Normal value: 7 to 100)
If DC is out of the normal value range, the protection
function works to turn off the power.
PS: Power supply voltage protection value (Normal value:
28 to 47)
If PS is out of the normal value range, the protection
function works to turn off the power.
REC-OUT
Not applied to these models.
REC-OUT
