RX-V340/RX-V340RDS/
HTR-5630/HTR-5630RDS/DSP-AX340
RX-V340/RX-V340RDS/HTR-5630/HTR-5630RDS/DSP-AX340
8
■ SPECIFICATIONS / 参考仕様
■ Audio Section/オーディオ部
Minimum RMS Output Power (Power Amp. Section)/
定格出力(パワーアンプ部)
(1 kHz, 0.1 % THD, 6 ohms)
MAIN L/R
U, C, J models .................................................. 70 W + 70 W
A, B, G, L, R, T, K models ................................60 W + 60 W
CENTER
U, C, J models .............................................................. 70 W
A, B, G, L, R, T, K models ............................................ 60 W
REAR L/R
U, C, J models .................................................. 70 W + 70 W
A, B, G, L, R, T, K models ................................60 W + 60 W
(1 kHz, 0.7 % THD, 6 ohms)
MAIN L/R
U, C models ...................................................... 75 W + 75 W
A, B, G, T, K models ......................................... 65 W + 65 W
CENTER
U, C models .................................................................. 75 W
A, B, G, T, K models ..................................................... 65 W
REAR L/R
U, C models ...................................................... 75 W + 75 W
A, B, G, T, K models ......................................... 65 W + 65 W
Maximum Power/実用最大出力
(EIAJ, 1 kHz, 10 % THD, 6 ohms)
MAIN L/R
R, T, K models ..................................................80 W + 80 W
J model..............................................................90 W + 90 W
CENTER
R, T, K models .............................................................. 80 W
J model.......................................................................... 90 W
REAR L/R
R, T, K models ..................................................80 W + 80 W
J model..............................................................90 W + 90 W
DIN Standard Output Power Per Channel/DINパワー
[B, G, L models]
(1 kHz, 0.7 % THD, 4 ohms)
MAIN L/R ................................................................. 75 W + 75 W
CENTER .............................................................................. 75 W
REAR L/R ................................................................ 75 W + 75 W
IEC Power /IECパワー[B, G, L models]
1 kHz, 0.1 % THD, 6 ohms ......................................60 W + 60 W
Dynamic Power Per Channel/ダイナミックパワー (IHF)
U, C, J models (6/4/2 ohms) ................................. 85/100/115 W
A, B, G, L, R, T, K models (6/4/2 ohms) ................. 75/95/105 W
Dynamic Headroom/ダイナミックヘッドルーム[U, C models]
6 ohms ............................................................................. 0.84 dB
Input Sensitivity / Input Impedance(入力感度/入力インピーダンス)
CD, etc. ........................................................ 150 mV / 47 k-ohms
EXT. DECODER
MAIN L/R, CENTER, SURROUND L/R, SUB WOOFER
.............................................................. 150 mV / 47 k-ohms
Maximum Input Signal Level/最大許容入力
(1 kHz, 0.5 % THD, Effect On)
CD, etc. ................................................................... 2.0 V or more
Output Level / Output Impedance (出力電圧/出力インピーダンス)
REC OUT .................................................... 150 mV / 1.2 k-ohms
SUB WOOFER (MAIN SP: Small) .................... 4 V / 1.2 k-ohms
Headphone Jack Rated Output / Impedance(ヘッドフォン出力/
出力インピーダンス)
CD, etc. (1 kHz, 150 mV, 8 ohms) ................... 0.3 V / 470 ohms
Frequency Response/周波数特性
CD, etc. to MAIN L/R (10 Hz to 100 kHz) ................... 0 / -3.0 dB
Total Harmonic Distortion/全高調波歪率
(1 kHz, 30 W, 6 ohms)
CD, etc. (Effect Off) to MAIN L/R SP OUT ...........0.06 % or less
Signal to Noise Ratio/信号対雑音比 (IHF-A network)
CD, etc. (Input shorted, EFFECT OFF) to MAIN L/R SP OUT
250mV ...........................................................100 dB or more
Residual Noise/残留ノイズ (IHF-A network)
MAIN L/R SP OUT ................................................ 150 µV or less
Channel Separation/チャンネルセパレーション
(Vol -30 dB, Effect Off)
CD, etc. (Input 5.1 k-ohms shorted, 1 kHz / 10 kHz)
.................................................... 60 dB or more / 45 dB or more
Tone Control Characteristics/トーンコントロール特性
BASS
Boost/Cut ..................................................... ±10 dB (100Hz)
TREBLE
Boost/Cut .................................................... ±10 dB (20 kHz)
Filter Characteristics/フィルター特性
MAIN, REAR L/R SP Small (H.P.F.) ...............90 Hz / 12 dB oct.
SUBWOOFER (L.P.F.) ....................................90 Hz / 18 dB oct.
■ Video Section/ビデオ部
Video Signal Type/ビデオ信号方式
U, C, R, T, K, J models....................................................... NTSC
A, B, G, L models .................................................................. PAL
Video Signal Level/ビデオ信号
.......................................................................... 1 Vp-p / 75 ohms
Maximum Input Level/最大許容入力
........................................................................................ 1.5 Vp-p
Signal to Noise Ratio/信号対雑音比
...............................................................................50 dB or more
Monitor Out Frequency Response/モニターアウト周波数帯域
Video Signal Level .................................... 5 Hz to 10 MHz, -3 dB
■ FM Section/FM部
Tuning Range
U, C models .................................................... 87.5 to 107.9 MHz
A, B, G, L, T, K models............................... 87.50 to 108.00 MHz
R model.............................. 87.5 to 108.0 / 87.50 to 108.00 MHz
J model ............................................................. 76.0 to 90.0 MHz
50dB Quieting Sensitivity/50dBSN感度 (IHF)
(1 kHz, 100 % Mod.)
Mono ................................................................. 2.0 µV (17.3 dBf)
Stereo ................................................................ 25 µV (39.2 dBf)
Usable Sensitivity/実用感度 (IHF)
Mono ................................................................. 1.0 µV (11.2 dBf)
Selectivity/選択度
at 400 kHz ........................................................................... 70 dB
Signal to Noise Ratio/信号対雑音比 (IHF)
Mono / Stereo .........................................................76 dB / 70 dB
Harmonic Distortion/歪率
(1 kHz)
Mono/Stereo ........................................................... 0.2 % / 0.3 %
Stereo Separation/ステレオセパレーション
1 kHz ................................................................................... 42 dB
Frequency Response/周波数特性
20 Hz to 15 kHz ......................................................... +0.5 / -2 dB
Antenna Input/アンテナ入力
.................................................................... 75 ohms unbalanced
