Lower unit (F100B)
6
No. Part name Q’ty Remarks
1 Lower unit 1
2 Plastic tie 1
Not reusable
3 Hose 1 7
×
145 mm
4 Check screw 1
5 Gasket 2
Not reusable
6 Dowel pin 2
7 Bolt 6 M10
×
45 mm
8 Drain screw 1
9Grommet 1
10 Bolt 1 M10
×
45 mm
11 Bolt 1 M10
×
70 mm
12 Spacer 1
13 Propeller 1
14 Washer 1
15 Washer 1
16 Cotter pin 1
Not reusable
17 Propeller nut 1
18 Trim tab 1
S60C6005
1
6
9
10
3
12
16
17
15
14
13
18
7
11
LT
LT
572
LT
LT
572
M
D
5
4
6
5
8
2
A
T
R
.
.
42 N
•
m (4.2 kgf
•
m, 30 ft
•
Ib)
T
R
.
.
55 N
•
m (5.5 kgf
•
m, 40 ft
•
Ib)
T
R
.
.
39 N
•
m (3.9 kgf
•
m, 28 ft
•
Ib)
T
R
.
.
39 N
•
m (3.9 kgf
•
m, 28 ft
•
Ib)
T
R
.
.
7 N
•
m (0.7 kgf
•
m, 5.1 ft
•
Ib)
Special service tools / Lower unit (F100B)
