Yamaha F100C - Power Trim and Tilt Unit (F100 B)

BRKT
Bracket unit
7-29
60C5D11
Power trim and tilt unit (F100B)
7
No. Part name Q’ty Remarks
1 Power trim and tilt unit 1
2 PTT motor lead 2
3 Shaft 1
4 Plastic tie 3
Not reusable
5 Circlip 1
6Bolt 2 M8
×
16 mm
7 Washer 2
8 Shaft 1
9 Bushing 6
10 Bolt 1 M6
×
10 mm
11 Ground lead 1
