Yamaha F100C - Page 217

60C5D11
7-10
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Shift rod 1
2 Bottom cowling 1
3 Shift rod bracket 1
4Bolt 1
5Spring 1
6Ball 1
7 Cotter pin 1
Not reusable
8 Washer 1
9 Bushing 2
10 Bolt 2 M6
×
25 mm
11 Grommet 1
12 Clip 2
13 Shift rod lever 1
14 Washer 1
15 Shift bracket 1
16 Bushing 1
17 Bolt 2 M6
×
40 mm
18 Bolt 4 M6
×
20 mm
19 Bracket 1
20 Trailer switch 1
21 Pilot water hose 1
22 Hook 2
23 Spring 2
24 Bolt 2 M6
×
12 mm
25 Washer 2
26 Lever 2
27 Wave washer 2
28 Bushing 2
29 Bolt 4 M6
×
30 mm
30 Plate 2
31 Bushing 2
32 Cowling lock lever 2
33 Bolt 4 M8
×
35 mm
34 Grommet 2
35 Grommet 1
36 Clamp 1
37 Bolt 1 M6
×
30 mm
38 Rubber seal 1
Bottom cowling
