Yamaha F100C - Page 261

60C5D11
7-54
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Upper case assembly 1
2 Oil pump body 1
3 Oil seal 1
Not reusable
4 Oil seal 1
Not reusable
5Bolt 6 M6
×
45 mm
6 Screw 6 M6
×
10 mm
7 Cover 1
8 Gasket 1
Not reusable
9 Shaft 1
10 O-ring 2
Not reusable
11 Oil seal 1
Not reusable
12 Dowel pin 2
13 O-ring 2
Not reusable
1.9
×
22.9 mm
14 Damper 2
15 Nut 2
16 Nut 2
17 Washer 2
18 Ground lead 1
19 Grease nipple 1
20 Washer 2
21 Bolt 1 M6
×
10 mm
Upper case (F100C)
