Yamaha F100C - Page 315

60C5D11
8-16
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Clip 1
2 Pinion stopper 1
3 Starter motor pinion 1
4Spring 1
5Bolt 2 M6
×
52 mm
6 Housing 1
7 Rubber seal 1
8 Bearing 1
9 Clutch assembly 1
10 E-clip 1
Not reusable
11 Thrust washer 1
12 Center bracket 1
13 Pinion shaft 1
14 Planetary gear 3
15 Outer gear 1
16 Plate 1
17 Armature 1
18 Stator 1
19 Brush assembly 1
20 Brush holder assembly 1
21 Plate 1
22 Thrust washer 1
23 Lower bracket 1
24 Screw 2 M4
×
14 mm
25 Bolt 2 M6
×
120 mm
26 Shift lever 1
27 Spring 1
28 Relay assembly 1
29 Nut 1
Starter motor
