Yamaha F100X - Page 208

5-32
E
POWR
OIL FILTER AND EXHAUST COVER
EXPLODED DIAGRAM
12
13
18
8
7
16
3
1
14
2
6
15 5
17
10
11
9
4
Å
E
1
7
20
26
25
24
12
14
15
11
17
22
19
21
18
23
16
10
8
9
6
5
4
3
6 Nm (0.6 m
•
kg, 4.3 ft
•
Ib)1st
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)2nd
18 Nm (1.8 m
•
kg, 13 ft
•
Ib)
6 × 20 mm
13
6 × 16 mm
6 × 30 mm
6 × 20 mm
6 × 16 mm
8 × 25 mm
6 × 12 mm
LT
LT
572572
17
16
A
2
Step Procedure/Part name Q’ty Service points
8 Exhaust cover 1
9 Gasket 1
10 Bolt 3
11 Pressure control valve (PCV)
cover
1
12 Spring 1
13 Pressure control valve (PCV) 1 Face the longer side towards the cylinder
block.
14 Grommet 1
15 Gasket 1
16 Bolt 2
17 Metal clamp 2
Not reusable
Not reusable
